Product Description
6 Way 12V 150A Rated Bus Bar Power Distribution Terminal Block For Auto Marine BlackFeatures:
1. The base is solid nylon, flame retardant material
2. Stainless steel stud screws with good rust resistance
3. Copper connection copper bars, good electrical conductivity
4. This product can be used in 300V AC and 48V DC DC systems, with a wide range of applications to meet customer needs.
Product application: It is usually used in the negative circuit collection wiring harness in the power supply system of the car, RV, yacht and ship.
Specification:
Type: Distribution Bar
Maximum voltage: 300V AC /48V DC
Rated current: 130A AC / 150A DC
Recessed mounting holes: 5mm
Material: base material nylon + transparent PC cover
Terminal screw: M4*6 (M4 stainless steel screw)
Terminal stud: M6*2 (M6 stainless steel screw)
Connection bar material: copper bar
Product size: 120*20*42.8MM
Color: Black
Note:
1.Transition: 1cm=10mm=0.39inch
2.Please allow 0-3mm error due to manual measurement. pls make sure you do not mind before you bid.
3.Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
Package Included:
1 x Distribution Bar
2 x Screws
Shipping
1. Free shipping
2. Parcel will be delivered 2-6 working day
3. Parcel will via USPS or FedEx from USA warehouse
